POS Network Segmentation and Payment Path Control

Retail networks span thousands of locations, each processing payment card data through point-of-sale systems connected to corporate infrastructure. A single compromised store can provide a path to every other location in the estate.

Back to Control
Control

Retail

When a guest Wi-Fi access point and a payment terminal share the same network, every customer browsing the internet is a potential path to payment card data.

100%

Payment network isolation from store IT

Zero

Persistent vendor paths to POS systems

4

Store network zones with independent governance

Full

PCI DSS 4.0 network segmentation evidence

The Challenge

Retail networks are distributed and high-value targets.

POS Compromise

Point-of-sale systems across thousands of locations create a massive attack surface for payment card data theft.

Flat Store Networks

Many retail locations share a single network for POS, back-office, CCTV, and guest Wi-Fi, enabling lateral movement from any entry point.

Supply Chain Risks

POS software vendors, payment processors, and maintenance contractors each create persistent pathways into the payment environment.

The Scenario

Scenario: Estate-Wide POS Compromise

Attackers compromise a POS software update server and distribute a modified update containing memory-scraping malware. The update propagates to 1,200 stores over a routine maintenance cycle. The malware captures payment card data from POS memory and exfiltrates it through the store internet connection, which shares the same network as the POS systems. Over eight weeks, 4.3 million payment card numbers are stolen. With Firevault Control, POS networks are physically separated from store internet connectivity. The malicious update cannot exfiltrate data because the POS network has no path to the internet. Software updates are delivered through controlled, authorised transfer windows with integrity verification.

"Our PCI assessor told us our segmentation was compliant. But it was VLAN-based. When the attackers compromised the switch management interface, every VLAN boundary in the estate became meaningless."

Module deployment · retail network

Where each Control module is deployed across stores, e-commerce, payments and vendors.

Retail estates carry an internet edge, a corporate office, store and POS systems, an e-commerce platform and the cardholder data environment that handles payments. Control puts a real boundary at every change of trust.

Grounded in PCI DSS v4 network segmentation guidance and NCSC retail sector guidance.
